Music Hall MMF-1.5 Turntable

Turntable

• Type: 3-speed full manual
• Motor: DC motor
• Driving Method: Belt drive
• Platter: 305mm dia. aluminum die-cast
• Speeds: 33 1/3, 45, and 78rpm
• Wow & Flutter: less than 0.1% WTD at 3KHz RMS(CD-4005)
• Limit: Less than 0.15% WTD at 3KHz RMS(CD-4005)
• S/N Ratio: More than 65dB (DIN-B) (SS-4242)
• Limit: More than 62dB (DIN-B) (SS-4242
• Speed Tolerance: 3000Hz +/-1%(CD-4005)
• Power Supply: DC12V，2.0A

Universal Power Supply

• Consumption: 4W
• Dimensions (WxDxH): 17.1" x 14.5" x 5" (435x367x127mm)
• Weight: 12lbs. (5.4Kg)

Cartridge

• Included Cartridge: Music Hall Melody
• Output Voltage: 2.5mV +/- 3dB at 1KHz 3.54cm/sec
• Channel Separation: measurement point 1KHz over 18dB
• Channel Balance: 25 dB or less at 1KHz
• Frequency Response: measurement point 10KHz / 1KHz 0 +/- 3dB
• Tracking Force: 2.0 +/- 0.5 grams
• Cartridge Type: Moving Magnet
• Stylus: Diamond
• Channel Separation: More than 15 dB at 1KHz (CD-4005)
• Channel Balance: Within 2.5 dB at 1KHz (CD-4005)
• Phono Output Level: 1.5~3.6 mV at 1KHz 5cm/sec (CD-4005)
• Line Output: 90-216 mV at 1KHz 5cm/sec (CD-4005)
• RIAA: 20Hz~20KHz

Tonearm

• Type: static balanced S-shaped
• Effective Arm Length: 230mm
• Overhang: 15mm
• Offset Angle: 22 degrees
• Tracking Error Angle: 3 degrees or less
• Rotation Movability: (1-rotation 4g)Applicable Cartridge Weight
• Anti-Skating Adjustment Range: 0~3g
• Arm Lifter: Oil damper type
• Height Of Stylus: 8~10.5mm
• Lifter Descent Time: 1.5~3 sec (stylus pressure
• Horizontal Sensitivity: less than 0.2g
• Vertical Sensitivity: less than 0.2g
