Vendor: AudioControl

AudioControl Model M6800 Amplifier

16-Channel DSP Amplifier with Network Control
$5,990.00
$5,990.00

AudioControl Authorized Dealer

​Dreamedia+

This is a Dreamedia+ product. To ensure the best possible experience and to comply with manufacturer online sales policies, a consultation with a Dreamedia specialist is required. Contact us by phone, chat, or email today for purchasing options and availability.

Need Help?

We're here to help. Call or chat with a Dreamedia specialist.

Free Shipping

Free nationwide shipping available!*

Free Returns

30 day guarantee.
AudioControl Model M6800 Amplifier

Unleash the Power of Pristine Sound with AudioControl's Model M6800 Amplifier

Imagine stepping into a space where every note of your favorite symphony, every strum of a guitar, and every beat of the drum is reproduced with such clarity and power that you feel enveloped in a cocoon of pure sound. This isn't just a dream—it's the reality offered by the AudioControl Model M6800 Amplifier. Designed for the audiophile, crafted for the connoisseur, the M6800 is the heart of a high-fidelity sound system that brings your music and movies to life.

The Epitome of High-Power Amplification

  • Stereo RMS Power (8 Ohms): 100 Watts per channel
  • Stereo RMS Power (4 Ohms): 200 Watts per channel
  • Bridged Power (8 Ohms): 400 Watts

The M6800 isn't just an amplifier; it's a powerhouse. With 16 channels of pristine amplification, delivering up to 200 watts per channel at 4 ohms, this matrix amplifier is designed to drive the most demanding home theater and multi-zone audio systems with ease. Whether you're looking to fill a large room with sound or wanting to create an immersive audio experience across multiple zones, the M6800 delivers the power you need.

Superior Digital Signal Processing

  • Built-in DSP: For precision sound calibration
  • DAC Sample Rate: 32 – 96 kHz
  • DAC Bit Depth: 16/24 bit

The M6800 boasts a sophisticated digital signal processor (DSP) that ensures your audio is not just loud, but crystal clear. The built-in DSP allows for detailed sound shaping and customization, ensuring that regardless of the genre, be it classical, rock, or cinematic scores, your audio is delivered with the utmost fidelity.

Unmatched Control and Connectivity

  • Remote Power Trigger: +12 VDC or Dry Contact Closure
  • Network Connection/Protocol: 10BaseT Ethernet TCP/IP
  • Communication Protocol: HTTP or Telnet

The modern home theater and audio systems require more than just brute force; they need brains. The M6800 is a smart amplifier, equipped with Ethernet connectivity for seamless integration into your home network. This allows for real-time monitoring and programming, ensuring that your system is always performing at its peak.

Tailored Audio Experience

  • Speaker Optimization Profiles: For tailored performance
  • Matrix Routing: Analog or two digital inputs to any zone output
  • Equalization: Network programmable graphic & parametric with user memories

The M6800 doesn't just play your audio; it perfects it. With built-in speaker optimization profiles and the ability to create custom profiles, this amplifier adapts to the unique characteristics of your speakers and room acoustics. The result is a sound that's not just heard, but felt.

Design and Build

  • Dimensions: 17” W x 15.5” D x 3.5” H (2U)
  • Weight: 21.0 lbs (9.5 kg)
  • Available Colors: Brushed Aluminum, Espresso Black

Crafted with a sleek 2U rack space design, the M6800 fits seamlessly into any home theater setup. Its robust build quality, born from AudioControl's commitment to manufacturing in Seattle, WA, USA, ensures reliability and longevity.

Features at a Glance

  • High-power amplification for multi-zone applications
  • Digital and analog inputs for flexible connectivity
  • Compact design for efficient rack space usage
  • Built-in speaker protection with AudioControl LightDrive anti-clipping technology
  • 5-year standard warranty for peace of mind

Installation and Integration

  • Installation Compatibility: Home and Commercial
  • Integration: With leading loudspeaker brands' DSP profiles

The M6800 is not just for the home; its versatility extends to commercial applications as well. Whether you're setting up a system for a restaurant, a conference hall, or a luxury residence, the M6800 integrates smoothly with both home automation and commercial control systems.

A Symphony of Features

  • 16-channel high-power network DSP matrix amplifier
  • Programmable graphic & parametric equalization with user memories
  • Ethernet port for status monitoring, source switching, and 12 Volt trigger control

Every feature of the M6800 has been thoughtfully designed to provide the user with unparalleled control over their audio experience. From the programmable equalization that allows for fine-tuning of the sound to the Ethernet port that offers advanced connectivity options, the M6800 is the conductor of your audio symphony.

Your Sound, Your Way

  • Custom profiles tailored for different acoustic spaces
  • Fine-tuning capability for the ultimate audio precision

With the M6800, you're not just playing music; you're crafting an auditory masterpiece. The ability to create custom profiles means that no matter the space, be it a cozy den or a sprawling living room, your sound can be tailored to fit it perfectly.

Dreamedia: Your Partner in Home Theater Excellence

At Dreamedia, we don't just sell products; we design experiences. Our team is ready to help you integrate the AudioControl Model M6800 Amplifier into your home theater system, ensuring that every movie night is an event and every song is a performance. With our expertise, we can help you unlock the full potential of this extraordinary amplifier.

Conclusion

The AudioControl Model M6800 Amplifier represents the pinnacle of audio amplification technology, offering power, precision, and control. It's an investment in not just a piece of equipment, but in an experience that will transform the way you listen to audio. With the M6800, your home entertainment system will be the envy of audiophiles everywhere. Embrace the power of pristine sound with the AudioControl Model M6800 Amplifier.

Our Review

Introduction

The AudioControl Model M6800 Amplifier enters the market as a robust solution for audiophiles and professional installers looking to elevate home theater and multi-zone audio systems. With a promise of high-power, network capabilities, and digital signal processing, the M6800 stands poised to transform how we experience audio in our personal and commercial spaces.

Design and Build Quality

The M6800 boasts a compact 2U rack space design, a thoughtful consideration for space economy in modern AV racks. Despite its relatively lightweight at 21.0 lbs, the amplifier does not compromise on build quality. The solid construction ensures durability while the dimensions (17” W x 15.5” D x 3.5” H) make it an easy fit for standard equipment racks. This design reflects a careful balance between robustness and convenience.

Power and Performance

Diving into the heart of the M6800, its power output is impressive, with 100W per channel at 8 Ohms and doubling to 200W at 4 Ohms. For those requiring even more punch, the 8 Ohms Bridged mode delivers a substantial 400W. Such versatility allows the M6800 to drive a wide range of speakers in diverse acoustic environments, ensuring that audio is delivered with clarity and strength, whether in a cozy living room or a spacious commercial venue.

Digital Signal Processing (DSP) and Audio Customization

The built-in DSP is a standout feature, offering users sophisticated audio shaping tools. Programmable graphic and parametric equalization with user memories enables precise audio tailoring. Speaker optimization profiles further refine the output, promising an audio experience that can be custom-fitted to the characteristics of the listening environment and the preferences of the user.

Connectivity and Integration

The M6800’s networking features are expansive, with an Ethernet port for status monitoring, source switching, and 12 Volt trigger control. This connectivity ensures seamless integration into smart home systems and compatibility with various third-party control systems, making the M6800 a versatile cornerstone for any sophisticated audio setup.

Flexibility and User Experience

The flexibility to use the M6800 as either a standalone matrix-amplifier or within a third-party control system cannot be understated. This duality speaks volumes about its potential to adapt to user needs. While the interface and configuration process cater to those with technical know-how, professional installers will appreciate the depth of control and customization available.

Protection and Reliability

AudioControl’s LightDrive anti-clipping speaker protection is a critical feature, safeguarding speakers from damage due to overdriving. The inclusion of a generous 5-year standard warranty underscores the manufacturer's commitment to reliability and customer satisfaction, suggesting a product built to last and perform consistently over time.

Pros and Cons

The M6800 is not without its challenges. The limitation to in-store pickup may inconvenience some potential buyers, and the intricacies of its configuration could be daunting for less technically inclined users. However, these cons are relatively minor when weighed against the amplifier’s high-power output, sophisticated DSP, and expansive integration capabilities.

Final Thoughts

The AudioControl Model M6800 Amplifier is a formidable contender in the realm of high-fidelity audio amplification. With its robust power, advanced DSP, and flexible integration options, it stands out as a versatile and powerful addition to any high-end audio system. Its ability to drive multiple zones with tailored sound profiles makes it an excellent choice for both residential and commercial installations. For those seeking pristine audio and sophisticated control in their sound systems, the M6800 represents a sound investment that promises to deliver top-tier audio performance.

Specifications

General

  • Model: Director Model M6800
  • Type: Matrix Amplifier
  • Number Of Channels: 16
  • Minimum Speaker Load: 4 Ohms
  • Available Colors: Brushed Aluminum, Espresso Black
  • Rack Space: 2U
  • Dimensions: 17” W x 15.5” D x 3.5” H
  • Weight: 21.0 lbs (9.5 kg)
  • Designed and Manufactured: Seattle, WA, USA

Amplification

  • Stereo RMS Power (8 Ohms): 100 Watts per channel
  • Stereo RMS Power (4 Ohms): 200 Watts per channel
  • Bridged Power (8 Ohms): 400 Watts
  • Bridgeable: Yes

Digital Signal Processing

  • DSP: Yes
  • Crosstalk: > 80 dB @ 1 kHz
  • Damping Factor: >300
  • Signal to Noise Ratio: >95 dB, A-wtd, ref full output
  • DAC Sample Rate: 32 – 96 kHz
  • DAC Bit Depth: 16/24 bit

Control

  • Remote Power Trigger: +12 VDC or Dry Contact Closure
  • Network Connection/Protocol: 10BaseT Ethernet TCP/IP
  • Communication Protocol: HTTP or Telnet

Inputs

  • Local Analog Inputs: 8 Stereo
  • Digital S/PDIF Inputs: 2
  • Toslink Inputs: 2
  • Input Sensitivity: 1 Vrms for full output, level at maximum
  • Input Gain: 30 dB

Outputs

  • Amplifier Channels: 16
  • Power Output (8 Ohms): 100W per channel
  • Power Output (4 Ohms): 200W per channel
  • Power Output (8 Ohms Bridged Mono): 400W
  • Preamp Audio Outputs: 8 Stereo Loop Outputs, 2 Digital S/PDIF Outputs

Features

  • Speaker Optimization Profiles: Built-In
  • Matrix Routing: Analog or two digital inputs to any zone output
  • Equalization: Network Programmable Graphic & Parametric with User Memories
  • Zone & Amplifier Naming: Assignable Names
  • Electronic Crossover: Programmable for Local Subwoofer Applications; Subsonic Filter
  • Anti-Clipping Protection: AudioControl LightDrive
  • Local Inputs: With Pass Thru / Loop Outputs
  • Digital Audio Bus Inputs: Dual
  • Installation Compatibility: Home and Commercial
