Marantz MODEL 10 Amplifier: Unmatched Audio Fidelity and Elegance

Exceptional Sound Quality

The Marantz MODEL 10 amplifier is a masterpiece of audio engineering, delivering a true high-end listening experience. With 200 watts per channel, it ensures pristine sound quality with dynamic depth and clarity, faithfully reproducing every nuance of your music.

Sophisticated Design and Build

Crafted with meticulous attention to detail, the MODEL 10 features a premium, robust design that complements its exceptional performance. The amplifier’s modern aesthetic, coupled with its refined chassis, adds a touch of elegance to any home audio setup.

Innovative Technology

Equipped with Marantz’s proprietary amplification technology, the MODEL 10 ensures exceptional sound reproduction with minimal distortion. The advanced power supply and high-performance components work together to create a highly efficient, low-noise amplification system.

Versatile Connectivity

Designed to seamlessly integrate into your audio system, the MODEL 10 features balanced XLR and unbalanced RCA inputs, offering flexibility for a wide range of devices. Whether connecting to a high-end audio player or preamp, it delivers superior performance with every connection.

Superior Power Handling

With its robust power handling capabilities, the MODEL 10 can effortlessly drive demanding speakers and handle peak audio levels without compromising performance, providing consistent and clean sound at all volumes.

Timeless Audio Engineering

Designed for the discerning audiophile, the Marantz MODEL 10 brings years of precision audio engineering into a single amplifier, combining modern technology with classic Marantz craftsmanship for a truly unrivaled listening experience.

Our Review

Coming Soon!.

Specifications

General

Unit (W × H × D mm): 440 × 192 × 473
Cabinet Size: 440 × 192 × 422
Net weight: 33.7kg
Packaging Dimensions (W × H × D mm): 600 × 379 × 540
Packaging gross weight: 39.0kg
Carton Color : 1 Color (Material color to Brown Printing
Panel Color: Black / Marantz Champagne
Front (Center) Panel: Anodized machined aluminum
Back-shell: AAnodized machined aluminum
Front panel illumination: Yes (All sides, Dimmer)
Side cover: Aluminum (Thickness to Max 15.8mm)
Top cover: Aluminum (Thickness to 6mm)
Top cover (Centor) ventilation hole material: Stainless mesh
Interior ilumination: Yes, dimmable
Rear Panel: Copper Plated
Chassis Material: Copper Plated
Bottom Layer / Bottom plate: Triple layer Copper plated
Front panel illumination: Yes (All sides, Dimmer)
Volume Knob: Solid aluminum (Bearing construction)
Input Selector: Solid aluminum (Bearing construction)
Foot: Solid Alminum Copper plated (H
Heatsink for Power Amplifier: Extruded Aluminum

Audio

Rated Output Power: 250W + 250W (8ohm,20Hz-20kHz,THD 0.05 %) 500W + 500W (4ohm,20Hz-20kHz,THD 0.05 %)
Speaker Impedance: 4~16ohm
Frequency Response: 5Hz~60kHz +0dB/-3dB 20Hz~20kHz +0dB/-0.3dB
Total Harmonic distortion: 0.005% (125W, 8ohm, 20-20kHz) (CCIF IMD, DFD IMD)
Damping Factor: 500 (8ohm, 20Hz-20kHz)
Input Sensitivity to Phono input: MM to 3.6 mV / 36 kohm
Input Sensitivity to Phono input: MC (Low) to 400 μV / 33 ohm
Input Sensitivity to Phono input: MC (Mid) to 400 μV / 100 ohm
Input Sensitivity to Phono input: MC (High) to 400 μV / 390 ohm
RIAA Deviation: 20 Hz - 20 kHz ±0.5 dB (MM/MC)
Phono Maximum Input: MM to 80mV
Phono Maximum Input: MC to 8mV
Input Sensitivity to CD/LINE/RECORDER: 350 mV/41kohm (Unbalanced) 700 mV/36kohm
Input Sensitivity to Power Amp input: Unbalanced to 1.58V / 41kohm (Gain to 29dB)
Input Sensitivity to Power Amp input: Balanced to 3.16V / 15kohm (Gain to 24dB)
SN Ratio: PHONO (MM) to 88dB
SN Ratio: PHONO (MC) to 76dB
SN Ratio: CD to 122dB
SN Ratio: Balanced to 122dB
Headphone Output Level: 130mW / 32 ohms
Tone Control: BASS to 50Hz ±10dB
Tone Control: TREBLE to 15kHz ±10dB
Power Consumption: 270W
Power Consumption: 0.1W (at Standby)
Audio/ Video: Yes (MM / MC)
Audio/ Video: Marantz Musical Premium Phono EQ w/ Selectable MC
Audio/ Video: impedance (3 position)
Audio/ Video: PHONO (MC Low) to 400 μV / 33Ω
Audio/ Video: PHONO (MC Mid) to 400 μV / 100Ω
Audio/ Video: PHONO (MC High) to 400 μV / 390Ω
Audio/ Video: PHONO (MM) to 3.6 mV / 39kΩ
Analog Input (include Phono) / REC Out (RCA): 4 /1 (LINE1, LINE2, PHONO
Balanced XLR input: 2
Power Amp Direct: Yes [RCA (Thick nickel plated independent terminals) / XLR]
Pre out: Yes [RCA (Thick nickel plated independent terminals) / XLR]
2 sets of Speaker Output: Yes (Bi-wiring)
Speaker Terminal: Marantz Original SPKT-100+ 2 (High quality and high-purity copper plated)
Headphone Output: 1 (Turns off the speaker automatically when headphone is inserted)

Control/ Other

Remote Control Bus Terminal: Yes (RC-5 In / Out)
Remote Internal / External Switch: Yes
Flasher Input: Yes
AC Inlet: Yes
Other: F.C.B.S. (Floating Control Bus System)
Remote Controller: 10 series Universal Remote control
Unit control (Button): Tact Switch to 1 POWER
Unit control (Knob): 2 VOLUME, INPUT SELECTOR
LED: POWER to 1 White
LED: Protection to 1 Orange
LED: Illumination (Edge) to White
LED: Interior to White
Front Panel Display: New HD TFT Color Display
Dimmer for Front Display: 20 steps
Level meter Yes: (HD Display)
Volume Display: -infinity/-99.5dB - 0dB / 0.5 step (default) 0-100 / 0.5 step switchable
Last Function Memory: Yes
Auto Standby Mode: Yes
Remote Controller: RC004PMND
Battery: Yes (AAA ×2)
Power Cord: Yes (ALL region / Audio Grade / OFC)
Other: CoA card
